The DSPIC30F3010-30I/SP devices contain extensive Digital Signal Processor (DSP) functionality within high-performance 16-bit microcontroller (MCU) architecture. High-Performance Modified RISC CPU, modified Harvard architecture. DSP Engine feature with dual data fetch, accumulator write back for DSP operations, as well as 16-bit single-cycle shift.
Parametrics
Absolute maximum ratings:(1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD and MCLR) (Note 1) : -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS: -0.3V to +5.5V; (5)Voltage on MCLR with respect to VSS: 0V to +13.25V; (6)Maximum current out of VSS pin: 300 mA; (7)Maximum current into VDD pin (Note 2): 250 mA; (8)Input clamp current, IIK (VI < 0 or VI > VDD): 1.0 mA; (9)Output clamp current, IOK (VO < 0 or VO > VDD) : 10 mA; (10)Maximum output current sunk by any I/O pin: 25 mA; (11)Maximum output current sourced by any I/O pin: 25 mA; (12)Maximum current sunk by all ports: 200 mA; (13)Maximum current sourced by all ports (Note 2): 200 mA.
Features
Features: (1)High-Performance Modified RISC CPU: Modified Harvard architecture; (2)DSP Engine: Dual data fetch, Accumulator write back for DSP operations; (3)High-current sink/source I/O pins: 25 mA/25 mA; (4)16-bit capture input functions; (5)16-bit compare/PWM output functions; (6)3-wire SPI modules (supports 4 Frame modes); (7)3 duty cycle generators; (8)Dedicated time base; (9)Programmable output polarity; (10)Dead-time control for Complementary mode; (11)Manual output control; (12)Trigger for A/D conversions.
